arri alexa mini
TECHNICAL DATA
| Feature | Details |
|---|---|
| Model | ALEXA MINI |
| Sensor Type | Super 35 format ARRI ALEV III CMOS sensor with Bayer pattern color filter array |
| Maximum Resolution | 3424 x 2202 |
| Sensor Size | 1.112 x 0.715" |
| Photosite Pitch | 8.25 μm |
| Dynamic Range | 14+ stops over the entire sensitivity range from EI 160 to EI 3200 |
| Exposure Index | EI 160-3200 |
| Shutter | Electronic, 5.0°- 356° or 1s - 1/8000s |
| Recording Formats | MXF/ARRIRAW, MXF/Apple ProRes (4444 XQ, 4444, 422 HQ, 422, 422 LT) |
| Frame Rates | 0.75 - 200 fps |
| Viewfinder Type | Multi Viewfinder MVF-1 with 3,2" flip-out monitor, Camera Control Panel (CCP-1) with option to daisy-chain MVF-1 |
| Color Output | Rec 709, Rec 2020, Log C, Custom Look (ARRI Look File ALF-2) |
| Power Consumption | min. 43 W to max. 84 W |
| Weight | 5 lbs |
| Dimensions | 5.5 x 4.9 x 7.3" |
OVERVIEW
THE GOLDEN STANDARD
The Mini LF combines the 4.5K large-format sensor of the Alexa LF with the lightweight and versatile design of the Alexa Mini, making it ARRI’s latest innovation in large-format filmmaking. Retaining the same dimensions and mounting options that crews have come to rely on with the Mini, the Mini LF seamlessly integrates into established workflows. Its standout addition is a new media bay located on the left side of the camera, accommodating the Codex Compact 1TB Drive. This drive, built specifically for the Mini LF, enables recording in both ProRes and ARRIRAW formats with blazing write speeds of up to 8Gb/s, eliminating the need for frequent formatting or card switching.
VERSATILE, COMPACT
The ARRI ALEXA Mini is the ultimate all-rounder in the ARRI camera family, designed to deliver exceptional performance in a compact, lightweight, and self-contained form. Its symmetrical design supports filming in any orientation, including upside-down and portrait mode, while multiple accessory points allow for highly creative mounting options. The camera’s interchangeable lens mounts accommodate a wide range of lenses, from B4 video and EF stills lenses to ARRI Signature Primes with the LPL mount, offering unmatched flexibility for any project.
ADAPTABLE
Built with modern brushless gimbals, multicopters, and specialized rigs in mind, the ALEXA Mini is lightweight enough for handheld use and compact enough for tight shooting spaces. Ideal for underwater, aerial, car, action, and 3D shoots, it adapts seamlessly to challenging environments. Operable via wireless remote, the ARRI MVF-1 multi viewfinder, or onboard controls, the ALEXA Mini combines versatility and user-friendly operation to deliver the best image quality in virtually any shooting scenario.
